8.0M~125.0M 請在此填寫或選擇
(*填寫時需要加K/M/G)
8~32pF 請在此填寫或選擇
| 溫度頻差VS溫度范圍 | ±20ppm | ±25ppm | ±30ppm | ±50ppm | ±100ppm |
|---|---|---|---|---|---|
| -20~70℃ | |||||
| -40~85℃ | |||||
| -40~105℃ | |||||
| -55~125℃ |
Specs
所選參數(shù)Item
KX32Nominal Frequency
左邊填寫Oscillation Mode
基頻/泛音Load Capacitance
左邊填寫Equivalent Series Resistance
40~500ΩFrequency Tolerance
左邊選擇Frequency Stability
左邊選擇Operating Temperature
左邊選擇Drive Level
10μW typical; 50μW max.Shunt Capacitance
2pF maxSpecial Requirement
左邊選擇Specs
所選參數(shù)Item
KX32Nominal Frequency
8.0M~125.0MOscillation Mode
基頻/泛音Load Capacitance
8~32pFEquivalent Series Resistance
40~500ΩFrequency Tolerance
±5ppm~±30ppmFrequency Stability
±10ppm~±100ppmOperating Temperature
-55℃ min;+125℃ maxDrive Level
10μW typical; 50μW max.Shunt Capacitance
2pF maxSpecial Requirement
有/無
